Product Overview
Wireless BYOD interfacing is simply enabled through the device’s native casting protocol (such as AirPlay®, Google Cast™, or Miracast™), without the need to install an app. For hands-free, effortless user operation, Dynamic Layout Mode™ is an innovative feature of the WAVE-101 that automatically adapts the on-screen layout to new incoming or disconnected source content. The WAVE-101 is equipped with a host of other convenient features for integrators and end users, including programmable display control, display of user-uploaded images and video media, YouTube™ Live streaming, support for cloud-based digital signage applications, and much more.
Wireless BYOD Connectivity
The WAVE-101 interfaces with a presenter’s iOS, Android, Mac, Chromebook, or Windows device over Wi-Fi®, and allows screen mirroring from up to four devices without the need to install an app. It can serve as an integrated, dual band access point, or be networked into an existing Wi-Fi installation. The WAVE-101 can provide simultaneous Wi-Fi and Miracast™ (Wi-Fi Direct®). In addition, the WAVE-101 supports Miracast over Infrastructure which allows Miracast over a facility Wi-Fi network or LAN, rather than over a direct wireless link. Please click here for complete information about wireless AV connectivity with the WAVE-101. (Note: One Miracast device connection is available at a time when a wireless P2P, or peer-to-peer connection is made to the WAVE-101.)
Applications
Classrooms – The WAVE-101 includes several features ideal for classroom instruction, such as managing multiple student presenters, the ability to broadcast an instruction session live over YouTube, and playback of local multimedia or YouTube source content.
Meeting and gathering spaces – The WAVE-101 is compact and can be discreetly installed near any available display. It is ideal for ad-hoc collaboration sessions in which presenters can share content through simple instructions on the welcome screen – including a PIN code for security.
Add-on to existing AV systems – This presentation device can be added into an AV switcher or matrix switcher, enhancing a new or existing system with wireless BYOD from multiple participants.
Technical Features
Wireless AV platform allows simultaneous content sharing for up to four 1080p presenters
Wireless screen casting with iOS, Android, Mac, Chromebook, and Windows devices through native AirPlay, Google Cast, or Miracast protocols (Note: One Miracast device connection is available at a time when a wireless P2P, or peer-to-peer connection is made to the WAVE-101)
Dynamic Layout Mode (patent pending) automatically adapts to incoming or disconnected source content, to optimize the way the content is presented on the screen
Selectable, fixed static layout modes available to determine the number of visible on-screen presenters
Instructor Mode allows a user to manage content, adjust audio volume, upload and play media content, stream YouTube, and switch between layouts
Supports YouTube Live streaming
Supports cloud-based digital signage platforms
Local storage available for playback of images and video
Optional Wi-Fi® access point with built-in firewall
Apple® iBeacon® device discovery speeds up connectivity for iOS devices and Mac computers
Supports Miracast over Infrastructure for use of facility Wi-Fi or Ethernet network
Wireless AV interfacing can be selectively enabled or disabled for each native platform
Supports wireless video up to 1080p30 4:2:0 (up to 1080p60 with Miracast)
Secure wireless and content sharing with randomly generated passwords and PIN codes, and a configurable firewall
Supports industry-standard, network security features and protocols such as WPA2-PSK, and AES-128 encryption
Programmable IP, RS-232 (with optional adapter), or TCP proxy (port 9001) display control based on time schedules
Automatic display control available with the AT-OCS-900N occupancy sensor
Centrally configure and manage WAVE-101 units with AMS (Atlona Management System™)
Includes installation guide, Wi-Fi adapter/antenna, VESA mount, and external universal power supply
Three-year limited product warranty
